Best selling products greatcity automatic stirrup bending machine factory

1.Bending and shearing mechanism: driven by imported servo motor, the bent arm can rotate and flex at high speed. The shearing mechanism completes the shearing action at high speed to ensure the bending accuracy of the steel bar.
2.Control system: This machine adopts foreign mature control system, high reliability. The control system has the function of fault identification and alarm.

Power:
Certification:
Scope:
Traction speed:
Application:
Quantity:
  • R7
  • Greatcity
  • 8462219000

Our  automatic stirrup bending machine 'compare advantages with similar products:

Our factory digests and absorbs European advanced technology and independently researches and develops CNC bending hoop machines with intellectual property rights.It is a combination of straightening,bending,and shearing functions.It is controlled by digital programs and can be bent to produce various shapes of rebars.Special equipment,the machine can bend double bars at the same time,high production efficiency,easy adjustment,favored by users.
1.special design structure, easy to deal with ribbed steel straightening, straightening ribbed steel does not hurt ribs.
2.The curve-type steel straightening mechanism improves the straightening effect of the steel bars and prevents axial reversal of the steel bars.
3.vertical straightening mechanism, can be individually straightened for each bar to ensure the quality of bar straightening;
4.All the rollers are made of high-quality alloy steel, high hardness, good wear resistance, and increase the service life;
5.There is a steel rebar control bar near the corner to ensure the bending quality.

R7 model automatic stirrup bending machine technical specifications:

MODEL

R7

process diameter of single rebar

4-10mm

process diameter of double rebar

4-8mm

max bending angle

180

max towing speed

60m/min

max bending speed

800

length accuracy

1mm

angular accuracy

1

processing quantity

2

power

21kw

steel processing shape

150type

working temperature

-5-40

weight

1980kg

dimension

3300*1000*1980mm


automatic stirrup bending machine  video link on youtube :
https://www.youtube.com/watch?v=npwgnHDCwX4&t=3s

R6 automatic stirrup bending machine 'description

· This Steel Bar Bending Machine  dopts servo controlling system;

· Automatically accomplish the functions of rebar's feeding, straighten, bending and cutting etc.;

· Max bending diameter of rebar is 10mm;

· Continuously bend various stirrup of plane figure;

· Widely used in construction industry and rebar manufacturing enterprise;

· High efficiency and accurate processing precision


This CNC automatic stirrup bending machine adopts CNC servo control system,which can automatically finish steel straightening,length measuring,bending hoop,cutting and other processes,can bend the maximum diameter of 10MM steel bar and continuously produce any product with any planar shape,widely used in the construction industry,Steel processing plants and other fields.In addition,the equipment has been improved several times since its production to better meet the actual needs of steel processing and production.

R7弯箍机_01


steel bar bending machine _06 (7)

steel bar bending machine _06 (8)

steel bar bending machine _06 (9)

steel bar bending machine _06 (10)







steel bar bending machine _06 (1)

Packaging and shipping of  automatic stirrup Bending Machine

Packaging: Wooden case for exportation

Shipping: By sea or by land

R7弯箍机_06

R7弯箍机_05

Xingtai Greatcity(JUDU) machinery manufacturing Co.LTD is located in the historical industrial zone,HEBEI province.Founded in 1999,we are a professional manufacturer of series of CNC automatic stirrup Bending Machine and rolling machine.For tewnty years in development,our company has always been adhering to credit the first bst quality in after sale service,innovations,self-improvement,adhere an independent intellectual property right as the core of scientific and technological innovation.the current bending machine rebar and horizontal lathes for the company's main product are sold throughout the country,some products exported to Asia,Africa,and other countries and regions,we are abide by integrity and innovation,entrepreneurial spirit,relying on leading research and development capabilities efficient manufacturing,stable quality and good service to meet the needs of our customers at home and abroad,the company has now passed the ISO9001:2000 international quality management system certification.
