Simple introduction :
This newly designed 3D wire bender adopts advanced design concept to realize double-row straightening machine. Small wheel set for fine line and large wheel set for coarse line; the cutter is set back to save more production time and achieve 360° unlimited rotation of the head.
The flexibility of the servo motr let the machine works amazingly with a high precision command.
Here below the general specification of the 3D CNC Steel Wire Bending Machine
Note that any customization is permissible
3D CNC Steel Wire Bending Machine technical specification
Model | 3D |
Diameter | Steel: 2-6 mm Ordinary wire:3-8 mm |
Type | hydraulic |
Hydraulic power motor | 2.2 kW |
Motor power servo motor | 5.5 kW |
Feeding wire | 10000.00 mm |
Traction Servo speed | 1:20 |
Molding/ turning speed | 1:5 |
Molding /turning power | 3.8*2 kW |
Lifting/ turning servo | 1:5/1:20 |
Lifting / turning servo | 0.75*2 kW |
Control shaft system | 5 |
Molding machine size | 3*1.35*1.95 mm |
Motorized machine size | 1*1*0.75 mm |
Input voltage | 380V/50Jz/3Ph |
Net weight | 2.8 T |
3D CNC Steel Wire Bending Machine video on youtube :
3D CNC Steel Wire Bending Machine working video on youtube
https://www.youtube.com/watch?v=vlPzLfL62jY
https://www.youtube.com/watch?v=9lZIgRcgzb8&t=8s
3D CNC Steel Wire Bending Machine
packaging information: standard export packing.
delievery time: 7-15 days after receiving the deposit.
Our have ourself freight agent, we can supply tracking ship service.
FAQ
1. Q: What is the power supply of the 3D CNC Steel Wire Bending Machine?
A: The standard power supply in china is 380V, 3P, 50Hz. We also can customized accordingly.
2. Q: What information should the customer provide to get an accurate quotation from us?
A: The customer should provide the related technical requirements, drawings, pictures, industrial voltage, planned output, etc
3. Q: What is the payment term A: The payment term is 30% down payment, and 70% before shipment(T/T mode), we also accept other
payment term, like L/C, DA, D/P etc
4. Q: What is the delivery time?
A: Normally the delivery time of the machine is 30 days after receive down payment.
5. Q: What is the warrantee period of the machine?
A: The warrantee period is one year since the date of B/L.
