Z28-315
Greatcity
8462419000
Anchor Bolts Thread Rolling Machine
The Z28-315 screw making machine thread rolling is maily used for processing precision standard parts of thread and high strength,including regular thread,trapezoid thread and modulax thread.The objective material to be processed inchcde carbon steel ,alloy steel and nonferrous metal with elongation over 10% and tensile srength less than 100kgf/mm⊃2;
greatcity threading rolling machine can equipped the auto feeding and loading machine. pls inquiry for details.
Z28-315 model rebar screw making machine thread rolling technical parameters:
| Model | Z28-315 |
| Object part for rolling diameter | Ø8-110mm |
| Object part for rolling thread range | 0.5-8mm |
| Inner dia. of roller wheels | Ø75mm |
| Width of both wheels | 50-120mm |
| Dia. of two roller wheels | Ø170-220mm |
| Max feeding power | 300Kn |
Hydraulic auto-feeding time regulation scope | 0.1-99.9 |
Mechanical transmission motor | 15kw/1450r/min |
Hydraulic cease time regulation scope | 5.5kw/1450r/min |
Cooling electric pump | 120w |
Outer sizes | 2150*1800*1600mm |
Weight | 4500kg |
Anchor Bolts Thread Rolling Machine detailed show :
Anchor Bolts Thread Rolling Machine Packing Details :
Plastic bag and then fumigation free wooden case.
Delivery :
within 10 days if machine is in stock;
producing according to customers' order within 15-25 days
1. What’s the price of threading rollers?
Re: Kindly please let me know your rod material and the detailed size, such as diameter and thread pitch, etc., so that we can check for you accordingly.
2. We have different rod diameter from 20-80mm, how to choose threading rollers?
Re: The threading roller will be suitable for various length and diameter, but for different thread pitch, it should be changed accordingly.
3. How to operate the Anchor Bolts Thread Rolling Machine, assuming it has auto cycle and foot pedal?
Re: The thread rolling machine is equipped with button control panel and foot pedal, so the working cycle can be exchanged as automatic work or inching.
4.Do you have corresponding machine - rebar diameter reducing machine ?
Re: We have the rebar diameter reducing machine,if you also need ,we can supply together with the thread rolling machine
