Factory Price CNC 4-10mm Steel Bar Stirrup Bender / Reinforcing Rebar Stirrup Bending Machine Automatic Pham

1.Bending and shearing mechanism: driven by imported servo motor, the bent arm can rotate and flex at high speed. The shearing mechanism completes the shearing action at high speed to ensure the bending accuracy of the steel bar.
2.Control system: This machine adopts foreign mature control system, high reliability. The control system has the function of fault identification and alarm.

Power:
Certification:
Scope:
Traction speed:
Application:
Quantity:
  • R7
  • Greatcity
  • 8462219000


Factory Price CNC 4-10mm Steel Bar Stirrup Bender / Reinforcing Rebar Stirrup Bending Machine Automatic Pham


production Descripton:

stirrup bending machine automatic pham CNC servo control system, can be done automatically reinforced straightening, cut to length, bending hoop, cutting and other process, the maximum diameter of 14mm can bend steel, continuous production of any planar shape of products, widely used in construction, a large steel plant and other fields. Further equipment since production improved after a few more perfect products and better meet the actual needs of steel processing.

stirrup bending machine automatic pham  technical specifications:

MODEL

R7

process diameter of single rebar

4-10mm

process diameter of double rebar

4-8mm

max bending angle

180

max towing speed

60m/min

max bending speed

800

length accuracy

1mm

angular accuracy

1

processing quantity

2

power

21kw

steel processing shape

150type

working temperature

-5-40

weight

1980kg

dimension

3300*1000*1980mm


We also have other models of this type machine including R6,R8 and R9 cnc automatic rebar

stirrup bender bending machine,please tell us your rebar information,so that we can quote you the right model of our machine accordingly.


stirrup bending machine automatic pham video link on youtube :
https://www.youtube.com/watch?v=npwgnHDCwX4&t=3s

rebar stirrup bending machine - greatcity machinery (25)

rebar stirrup bending machine - greatcity machinery (26)

rebar stirrup bending machine - greatcity machinery (27)

R7 stirrup bending machine customer visting - greatcity machinery

stirrup bending machine automatic pham Features

1.High power feeding Servo Motor's To Ensure Straightening, Bending & Cutting Accuracy.

2.larg storage Capacity can save 500 Processing Geometric Designs, High Degree Automation.

3.Siemens Touchable Screen & Panasonic PLC.

4.Production Capacity 280-320 Tons 10 Hours 2 shift Per Day/ 26 Days a month.

5.Different shapes can be processed continuously without stop, furthermore no need to stop

the processing while adjusting the bending angle.

steel bar bending machine _06 (9)

steel bar bending machine _06 (10)

Recommended application industry:

This stirrup bending machine automatic pham is widely used in the construction industry,large steel processing plants,and high-speed railway,high way,water conservancy construction,etc.

r7 stirrup bending machine shipping

Packing &shipping :

We test the stirrup bending machine automatic pham before it is packaged and transported:

One set Automatic Stirrup bending machine
1, could packed in iron frame, than cover by tarpaulin
2, could packed in wooden case,

Machine packed in two wooden cases, total diminsion 17.76CBM, gross weight 3166kgs.
3, also could packed in nude

Customer can select the spare parts:

air compressor and flexible framework


steel bar bending machine _06 (1)

Warranty:


12months Quality warranty period (after put into operation formally).

we will send the english user manual and video with the machine after u place order, if not enough, we can teach you online.

Provide technical guide for stirrup bending machine forever.

After Quality Warranty period of stirrup bending machine, will provide the spare parts with cost price.

All the machines provided by our factory will be tested before ship.
