Z28-150B
Greatcity
8462419000
Application:
Ball Screw Thread Rolling Rolling Machine Mainly used for all kinds of external thread, including the common thread, trapezoidal thread and modulus thread.
It also can do the rolling process, forming, slidabrading, knurling etc..
Apply for all kinds of carbon steel, alloy steel and non-ferrous metals,
the elongation is more than 10%, the compressive strength is less than 100 KGF/m m2.
Ball Screw Thread Rolling Rolling Machine is suitable for machining thin-wall pipe thread of 5mm-56mm, can process ordinary thread,
and can also process trapezoidal thread. It is the preferred product for processing building top column and bridge top column
SPECIFICATIONS FOR GREATCITY Z28-150B | |||
Rolled thread range | mm | Φ5-65 | |
Hobbing wheel range | mm | outside dia:Φ120-170 hole dia:Φ75 Max width:100 | |
Maximum rolling pressure | kn | 200 | |
Main axis | . | Obiquity +5 | |
Hydraulic auto feeding time regulation range | s | 0.1-99.9 | |
Cease time regulation range | s | 0.1-99.9 | |
sMain axis transmission power | kw | 11kw-4 | |
Hydraulic transmission power | kw | 2.2 | |
machine weight | kg | 2800kg | |
Dimensions | mm | 2500*1450*1650 |
Ball Screw Thread Rolling Rolling Machine video link on youtube
https://www.youtube.com/watch?v=PJHxY6FLL4Y
1. Do you have any warranty?
Yes, we have. Two years warranty on host machine is given. Six months free replacement warranty for spare parts.
2. How is your after-sale service?
We have a professional technology supporting team for your timely services. You can get the help you need in time by telephone, webcam, online chat (Google talk, Facebook, Skype). Please contact us once the machine has any problem. Best service will be offered.
3. What certification do you have?
All of our iron rod thread rolling machine have the CE certification which ensures the quality and safety. Our machines are under strict quality management to ensure good quality. Because we fully understand that it will be a great trouble if machine have any problem during working at oversea.
4. Will you teach how to use the Ball Screw Thread Rolling Rolling Machine?
Yes, we can provide a complete user manual and usage video for instruction and application. And 24/7 online consultant service ensure you whatever problem and whenever you meet, you can solve easily. It is easy to operate by anyone with the instructions.
5. How about the shipment?
The machine will be shipped within 2-3 days after the receipt of your payment.
6. Can visit your factory?
Welcome to our factory. We would like to make invitation letter for you. Hope we can cooperate with you for a long term.
if any pipe thread rolling machine feel free to contact me !
Application:
Ball Screw Thread Rolling Rolling Machine Mainly used for all kinds of external thread, including the common thread, trapezoidal thread and modulus thread.
It also can do the rolling process, forming, slidabrading, knurling etc..
Apply for all kinds of carbon steel, alloy steel and non-ferrous metals,
the elongation is more than 10%, the compressive strength is less than 100 KGF/m m2.
Ball Screw Thread Rolling Rolling Machine is suitable for machining thin-wall pipe thread of 5mm-56mm, can process ordinary thread,
and can also process trapezoidal thread. It is the preferred product for processing building top column and bridge top column
SPECIFICATIONS FOR GREATCITY Z28-150B | |||
Rolled thread range | mm | Φ5-65 | |
Hobbing wheel range | mm | outside dia:Φ120-170 hole dia:Φ75 Max width:100 | |
Maximum rolling pressure | kn | 200 | |
Main axis | . | Obiquity +5 | |
Hydraulic auto feeding time regulation range | s | 0.1-99.9 | |
Cease time regulation range | s | 0.1-99.9 | |
sMain axis transmission power | kw | 11kw-4 | |
Hydraulic transmission power | kw | 2.2 | |
machine weight | kg | 2800kg | |
Dimensions | mm | 2500*1450*1650 |
Ball Screw Thread Rolling Rolling Machine video link on youtube
https://www.youtube.com/watch?v=PJHxY6FLL4Y
1. Do you have any warranty?
Yes, we have. Two years warranty on host machine is given. Six months free replacement warranty for spare parts.
2. How is your after-sale service?
We have a professional technology supporting team for your timely services. You can get the help you need in time by telephone, webcam, online chat (Google talk, Facebook, Skype). Please contact us once the machine has any problem. Best service will be offered.
3. What certification do you have?
All of our iron rod thread rolling machine have the CE certification which ensures the quality and safety. Our machines are under strict quality management to ensure good quality. Because we fully understand that it will be a great trouble if machine have any problem during working at oversea.
4. Will you teach how to use the Ball Screw Thread Rolling Rolling Machine?
Yes, we can provide a complete user manual and usage video for instruction and application. And 24/7 online consultant service ensure you whatever problem and whenever you meet, you can solve easily. It is easy to operate by anyone with the instructions.
5. How about the shipment?
The machine will be shipped within 2-3 days after the receipt of your payment.
6. Can visit your factory?
Welcome to our factory. We would like to make invitation letter for you. Hope we can cooperate with you for a long term.
if any pipe thread rolling machine feel free to contact me !
