High Precise CNC Automatic Hydraulic Rebar Stirrup Bending Machine

Max bending diameter of rebar is 12mm
Continuously bend various stirrup of plane figure;
Widely used in construction industry and rebar manufacturing enterprise;
High efficiency and accurate processing precision.

Power:
Automation:
Automatic:
Material:
Usage::
Quantity:
  • R8
  • Greatcity
  • 8462219000

High Precise automatic stirrup  bending machine is the improvement of the structure of the rebar bending machine, this machine adopts CNC servo control system, can automatically complete rebar straightening, fixing size, cutting and other processed. It can continous bend any shape products, widely used in the construction industry, large steel processing plants and other fields. In addition, since the production of equipment has been improved several times, it is more profect, more able to meet the actual production needs of steel bar processing. It constitute with two set of horizontal and vertical straightening wheels, and 4 pieces traction wheels, driven by a servo motor to be ensure the reinforced straightening achieve the best accuracy. this machine is one type of steel bar processing machines.

This High Precise automatic stirrup  bending machine has a reducer motor, big gears, small gears, bending panel, the characterized is the structure of the double stage brake motor and reducer direct as a reducer, the pinion and the gear meshing two stage reducer, gear always drives the bending disk rotation, bending disk is arranged on the central shaft hole and a plurality of bending the shaft hole, positioning working table bar are respectively arranged on the positioning shaft hole. since the double stage braking motor and reducer for direct reduction, input and output speed accurately, the bending speed is stable and accurate, and can be used to automatically control the conversion speed electrical brake can ensure the bending angle. This machine use the positive andnegative rotation of the motor to make two-way bending of the steel bar. The center shaft is replaceable for easy maintenance. Intelligent control can be adopted.


R8 High Precise automatic stirrup  bending machine  parameter :

Model

R8

Number of processing

2

Single bar diameter (mm)

5-12

Power (kw)

21

Double bar diameter (mm)

5-10

Shape processing (kinds)

500

Max bending angle ( °)

180

Working temperature (°C)

-5 -- 40

Max towing speed (m / min)

130

Weight (kg)

2980

Max bending speed ( °/ sec )

1460

Dimensiion (mm)

3510*1510*2310

Length accuracy (mm)

1

Average power(kw / h)

7



R8 High Precise automatic stirrup  bending machine picture show

reahr stirrup bending machine (2)

reahr stirrup bending machine (3)

reahr stirrup bending machine (4)

reahr stirrup bending machine (5)

reahr stirrup bending machine (6)

reahr stirrup bending machine (7)



automatic stirrup bending machine workpiece (1)

customer visting



The package of the High Precise automatic stirrup  bending machine is standard export wooden package

The shipping way include ship, airplane and truck etc.

STIRRUP BENDING MACHINE PACKING

1. What is the materials using for this High Precise automatic stirrup  bending machine?
Round steel and thread steel.

2. What is the max bending diameter?
Max bending diameter is 14mm, we can also custome-made for you.

3. Can you make the english language or other language of the CNC control system for the customers?
Yes. Of course. We can make different language for the cnc control. Just tell us which language you need.

4. Can you change the machine's color for the customers?
Yes. We can make the color as what you want.

5. What is the delivery time?
If we have machines in stock, delivery time is 2-3 days. If we don't have the stock. The delivery time is 5-8 days.

6. What is the type of transportation?

We can send to you by LCL and FCL by ship, or by land, or by air, all is available.
