JD-3D-308
Greatcity
8463300000
Service great city , got greater business , please select Greatcity wire bending machine.
The features of rebar 3d cnc automatic wire bending machine
3d CNC Stirrup Bending Machine is a turning machine. As the name suggests, it is a device that rotates the working head, does not turn the wire, and forms a three-dimensional angle. The characteristics of the rotary head machine are suitable for products with large diameter and rod type. The stability is very good. If the configuration is a high-speed motor, the production speed will be very fast. The structure of the rotary head machine is very intuitive, and the debugging is very convenient. The future is the mainstream model of the wire bending equipment.
3d cnc automatic wire bending machine technical specification
Model | 3D |
Diameter | Steel: 4-6 mm Ordinary wire: 3-8 mm |
Type | hydraulic |
Hydraulic power motor | 2.2 kW |
Motor power servo motor | 5.5 kW |
Feeding wire | 10000.00 mm |
Traction Servo speed | 1:20 |
Molding/ turning speed | 1:5 |
Molding /turning power | 3.8*2 kW |
Lifting/ turning servo | 1:5/1:20 |
Lifting / turning servo | 0.75*2 kW |
Control shaft system | 5 |
Molding machine size | 3*1.35*1.95 mm |
Motorized machine size | 1*1*0.75 mm |
Input voltage | 380V/50Jz/3Ph |
Net weight | 2.8 T |
3d cnc automatic wire bending machine video on youtube :
https://www.youtube.com/@mengrita9445
Application industry of rebar 3d automatic bending machine is mainly used for kitchen and bathroom hardware, garden tools, supermarket shelves, furniture seats and other 3-8mm wire diameter fittings.
Our Company :
Xingtai Greatcity(JUDU) machinery manufacturing Co.LTD is located in the historical industrial zone,HEBEI province.Founded in 1999,we are a professional manufacturer of series of 2d wire bending machine , 3d wire bending machine and wire bending machine with butting welder .For tewnty years in development,our company has always been adhering to credit the first bst quality in after sale service,innovations,self-improvement,adhere an independent intellectual property right as the core of scientific and technological innovation.the current bending machine rebar and horizontal lathes for the company's main product are sold throughout the country,some products exported to Asia,Africa,and other countries and regions,we are abide by integrity and innovation,entrepreneurial spirit,relying on leading research and development capabilities efficient manufacturing,stable quality and good service to meet the needs of our customers at home and abroad,the company has now passed the ISO9001:2000 international quality management system certification.
Packing of 3d cnc automatic wire bending machine
1. 1 pc wood cartton ,carton weight 1000kg,dimension:2800mm*850mm*1500mm.
2. The packing can do as customers' requirement.
Shipping
By sea to your nearest port;
By air to your nearest airport;
By express (DHL,UPS,FEDEX,TNT,EMS)to your door;
Ship to the warehouse in China according to the customers' requirement
1. Q: How about the after-sale service?
A: We have a strong team, specialized in after-sale service. We can arrange engineers to do service for you.
2. Q: Are you factory or trading company?
A: We are a factory in this field nearly 20 years
3. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Xingtai City. Hebei province. You can fly to zhengding airport and or by high-speed train directly. I will pick you up .
4.Q:How does your factory do regarding quality control?
A:Quality is priority. We always attach great importance to quality controlling from the beginning.and we have CE certificate.
Contact us:
