Z28-200
Greatcity
8462419000
roll thread machine price is divided into two axis rolling machine and three axis thread rolling machine
1, two axis wire rolling machine has very strong superiority in hardware building, automobile and motorcycle fittings, traffic power, standard parts.
2, three axis rolling machine is triangle support in the pipe thread processing industry, true fidelity roundness, concentricity and perpendicularity
It is a multifunctional cold extrusion rolling thread machine, the workpiece in the cold rolling pressure range can be made to straight lines, twill, spur, helical and bevel gear spline rolling; straightening, necking, rolling light and various rolling forming. The machine has safe and reliable electric liquid control system and implementation, which can make each work cycle in manual, semi-automatic and automatic selection in three ways. The cold rolling is an advanced non cutting process, which can effectively improve the internal and surface quality of workpiece, the radial compressive stress produced during processing, and can significantly improve the fatigue strength and torsion strength of the workpiece. It is an ideal process with high efficiency, energy saving and low consumption.
roll thread machine price can equipped the auto feeding and loading machine. pls inquiry for details.
SPECIFICATIONS FOR GREATCITY thread rolling machine mini ZP28-200 | |||
Rolled thread range | mm | Φ5-65 | |
Hobbing wheel range | mm | outside dia:Φ120-170 hole dia:Φ75 Max width:100 | |
Maximum rolling pressure | kn | 200 | |
Main axis | . | Obiquity +5 | |
Hydraulic auto feeding time regulation range | s | 0.1-99.9 | |
Cease time regulation range | s | 0.1-99.9 | |
sMain axis transmission power | kw | 11kw-4 | |
Hydraulic transmission power | kw | 2.2 | |
machine weight | kg | 2800kg | |
Dimensions | mm | 2500*1450*1650 |
Thread rolling machine price video link on youtube :
https://www.youtube.com/watch?v=D_t1gnynkCs
Working principle of Thread rolling machine price:
L and R are two pairs of involute rolling wheels with the same parameters, which are installed on two spindles of the rebar thread rolling machines, and can rotate synchronously under the drive of the transmission mechanism.The R wheel can be driven by the oil cylinder for radial feed motion, and the L wheel can be adjusted by adjusting the mechanism to coincide with the indentation of the R wheel on the surface of the workpiece P. The P locate the two center hole clamping, the adjustment fixture can make the axial movement in the force around the fixture O and spindle parallel to the axis of an angle, to ensure that the workpiece in the cold rolling process and keep two rolling wheels to roll in the free state, and convenient clamping the workpiece. The structure size, geometrical tolerance and technical requirements of the rolling wheel are formulated according to the rolling wheel and cylindrical measuring gear. The length of the normal line or the cross bar distance of the rolling wheel M is calculated according to the spline data of the gear, and the required material can be Cr12MoV (hardness 59 ~ 62HRC)
Xingtai Judu Technology Co.,Ltd is located in the historical industrial zone, Hebei province. Founded in 1999, we are a professional manufacturer of series of CNC stirrup bending machine and Thread rolling machine price. For twenty years in development, our company has always been adhering to credit the first best quality in after sale service, innovation, self-improvement, adhere an independent intellectual property right as the core of scientific and technological innovation. The current steel hoop bending machine and horizontal lathes for the company's main product are sold throughout the country, some products exported to Asia, Africa, and other countries and regions, we are abide by integrity and innovation, entrepreneurial spirit, relying on leading research and development capabilities efficient manufacturing, stable quality and good service to meet the needs of our customers at home and abroad, the company has now passed the ISO9001:2000 international quality management system certification.
"Greatcity" trademark has been identified as an unique brand name product that got the honorary title among many.
Within more than 20 years of development besides struggles, GreatCity is still keeping up its effort to maintain a brilliant business success in whole over the world due to its hardworking, courage and the will to improve its creation for customer satisfaction and maintain the reputation to be the best Chinese machinery manufacturer.
Packaging information: standard export non-fumigation wooden packing for Thread rolling machine price .you can choose by sea container or air. We have our own farwarder. We can check the delivery information timely. You can also use forwarder by yours. We will contact with him in the first time.
Shipping time:within 3-5 days after receiving the deposi
1. Help you choose the most suitable Thread rolling machine price .
2. Making the machine according to your request.
3. Give you machine’s details and video for help you use the machine more better.
4. One year warranty
5. Quality problem,we will send you the accessories.
6. Free repair whole using life without extra charge.
