Commercial Automatic Metal Hanger Machine / Wire Hanger Machine / galvanized steel wire hanger making machine

This automatic galvanized steel wire hanger making machine adopts full-automatic numerical control, accurate wire feeding, stable operation, low noise, can realize man-machine dialogue, and one machine can produce multiple hangers. A worker can manage 4-8 machines, can weld automatically, and save labor for you. The production capacity is 15 pieces per minute.

Wire diameter:
Color:
Power:
feeding wire::
Name::
Quantity:
  • JD-CH5
  • Greatcity
  • 8463300000

Brief Introduction of automatic galvanized steel wire hanger making machine

1.The wire hanger forming machine is in sheet plate welded structure, with internal stress

eliminated by vibration aging technology, high strength and good rigidity of machine.

2.Double hydraulic oil cylinder is applied for upper transmission, provided with mechanical limit

stopper and synchronous torsion bar, typical of stable and reliable operation, as well as high

precision.

3.Electrical control and manual fine-tuning mode are adopted for distance of rear stopper and

stroke of gliding block, and fitted with digital display device, easy and quick in use.

4.Upper die is fitted with deflection compensation device


Applications of automatic galvanized steel wire hanger making machine

The hangers made by the machine can be used in a wide range of applications. They can be applied to the clothing market, hotels, various large supermarkets, clothing stores, and retail to individuals. Hangers in our lives are ubiquitous.

automatic galvanized steel wire hanger making machine video on youtube

automatic galvanized steel wire hanger making machine technical specification

Model

JD-CH5

JD-CH-5P

JD-CH-5W

JD-CH-5W

Wire size

1.5-4.5mm

1.5-4.5mm

1.5-4.5mm

1.5-4.5mm

Function



Common

PVC coating

welding

wleding and rivet end

Welding machine

No

No

Yes

Yes

Feeding length

500mm(11-19inch)

500mm(11-19inch)

500mm(11-19inch)

500mm(11-19inch)

Production rate

50~60(pcs/minute)

30-40(pcs/minute)

30(pcs/minute)

30(pcs/minute)

Motor power

2.2kw

2.2kw

2.2kw

3.7kw

Size(mm)

2500X1460X1580

2500X1460X1580

2700X1460X1580

3600X1530X16800

Weight

1300KG

1300KG

1400KG

1400KG

hanger making machine

hanger making machine

hanger making machine

hanger making machine

hanger making machine

Advantage of automatic galvanized steel wire hanger making machine

Hanger machine adopts automatic CNC, accurate wire feeding, stable operation and low sound. One machine can produce a variety of hangers. A worker can manage 4-8 machines, which can save labor.
1. The length of the delivery line.
2. The speed can be adjusted according to the wire diameter.
3. The output is high and fast, and the fastest can produce 45 per minute.
4. The most convenient is to change the mold (the style of the hanger) is convenient and simple, input the required length of the wire on the screen, and move the position of the cutter.

hanger making machine

Packaging information: standard export wooden case packing with strong pallet for automatic galvanized steel wire hanger making machine

We have our own farwarder. and check the delivery information timely.

You can also choose your own forwarder . We will contact with him ASAP.

Delivery time: 7-15 days after receiving the deposit
