CNC Automatic Steel Bar Bending Machine controlled by servo system, can automatically accomplish elastic,straighten,stirrup bending, cutting and so on.
Stirrup bending Machine is an full-automatic CNC stirrup bar straightening and bending equipment used on construction project. It has high working efficiency of 30 pieces per min with computer controled, which ensures the high accuracy, can bend the stirrup bar into various angles. And it is easy to operate ,with safe working, reliable quality and quite high efficiency.
Application: Widely used in construction industry and rebar manufacturing enterprise; for steel wire rod,steel bar, steel rebar, etc.
Characteristic
1. Automatic wire feeding system ( PLC ).
2. Split, multi-blade design (patented) to reduce consumption costs
3. Large storage capacity can save 300 processing geometric graphics, high degree automation
4. Automatic double wire intake system, high processing efficiency
6. High power feeding motor to ensure bending bar accuracy.
7. The intelligent fault identification alarm system maintenance more convenient
8. Aerodynamic design observation door, easy adjustment and maintenance, and more security and fast.
9. Heavy-duty design line planes, equipped with a brake and buffer device can prevent chaotic lines
caused by downtime
10.High quality special material and high treatment to make straightening wheels, traction wheels, the
metering wheel, longer life with lower operating costs
11. Touch-screen console, easy to operate, and more fast
12. Control systems Electric parts: CHINESE TOP 1 BRAND.
MODEL | R7 |
process diameter of single rebar | 4-10mm |
process diameter of double rebar | 4-8mm |
max bending angle | 180 |
max towing speed | 60m/min |
max bending speed | 800 |
length accuracy | 1mm |
angular accuracy | 1 |
processing quantity | 2 |
power | 21kw |
steel processing shape | 150type |
working temperature | -5-40 |
weight | 1980kg |
dimension | 3300*1000*1980mm |
CNC Automatic Steel Bar Bending Machine video link on youtube :
https://www.youtube.com/watch?v=npwgnHDCwX4&t=3s
Packaging
CNC Automatic Steel Bar Bending Machine Free fumigation safe Wood case package.
MOQ
1set can be acceptable for trail order.
Over 3sets can have wholesale price. Welcome to join us as our sales agent in your market.
OEM and ODM
changing on design , color ,: acceptable(welcome)
develop on artwork and sketch : acceptable
QC
Third party inspection : acceptable
1 year guarantee for quality problems
Delivery time:
3 days for our own design.(motor:380v 50hz 3phases)
10 days for cusmoized model.
Payment :
TT, 30% deposit ,70% before shippment.
L/C at sight (high bank charge, not suggest , but acceptable )
100%TT in advance (specially for air shipment or small amount)
Available shipment by :
Nearest is FOBxingang
