Factory Price 2D CNC Wire Bender Bending Machine

Wire Bender Bending Machine without the need of the special mold, it greatly reduces the time and cost of the newly developed product; the stereoscopic molding can produce a three-dimensional shape line molding product; with an auxiliary lifting platform, it can further guarantee the production.
The stability and consistency of the product; the cutting knife can move downward to allow more space for product molding.

Diameter of wire:
Machine Type:
Material:
Applicable wire:
Control system:
Quantity:
  • ZD-2D-308
  • Greatcity
  • 8463300000

General Description:

The widely used  Wire Bender Bending Machine is a fully automatic machine for producing various two-dimensional die pressing parts. As long as the parameters are set on the operating table, the ideal two-dimensional shape can be bended at one time without additional dies. The line diameter range is suitable for 2.0-6.0 mm.

Processing wire, steel wire, stainless steel wire, non-ferrous wire (round, square, flat), bending, square, round, hexagonal, elliptical irregular shape and various flat buttons, hooks.


ZD-2D-308 model   Wire Bender Bending Machine  technical specification:


Model

ZD-2D-308

number of  axles

3

processing wire dameter range

3—8mm (iron wire )

Number of feeder wheels (group)

3

Applicable wire

Round wire, flat wire  square wire (suitable for any wire material)

Storage

10,000 data, 300 actions in a group

minimum feeding speed(m/min)

22

Servo motor power of feeding shaft(kW)

2.6

Power of Servomotor for Cutter Shaft(kW)

2.0

Power of Folded Axis Servomotor(kW)

2.0

Direction of action

Internal and external die can be lifted and bended in both directions.

Feeding  accuracy(mm)

±0.1

minimum bending speed

800rmp/min,angle±180º

Capacity

20-24pcs/min,(200*200mm square shape)

operating system

32-bit Chinese and English (with upload and download function)

Input power supply

380V,50HZ/60HZ

weight (KG)

800

Dimension (length*width*height mm)

3000×1000×1400

 Wire Bender Bending Machine  video link on youtube :

Product Application of widely used Wire Bender Bending Machine



1.Automobile accessories: car seat frame, door lock rod, snake spring (including single snake and double snake), car cat head spring, car seat belt spring, car seat wire accessories, motorcycle accessories, bicycle accessories and hanging basket are more suitable for production with wire forming machine;

2.Daily hardware products: kitchen display rack, clothes rack, egg beater, cabinet basket, refrigerator rack, bathroom clothes rack line products, supermarket shopping basket, trolley, display pendant, etc.

3.Wire crafts, lighting products, fishing gear accessories, including wine racks, fruit kettles in KTV, Christmas gifts, etc., are all wrapped with different shapes of wire or wire plane or three-dimensional parts.

4.All kinds of cage processing: pet cage, bird cage, dog cage, cat cage, breeding cage, trap cage, etc.

5.Clothes hanger, shoe hook, curtain hook, shelf hook, display hook and other hooks.


wire bending machine

wire bending machine

wire bending machine

wire bending machine

wire bending machine

wire bending machine

2D wire bending machine

Features of widely used Wire Bender Bending Machine :

1.CNC two-dimensional steel wire bending machine, corner with the production of different products. The debugging time is short. New products need only simple adjustment, and can be produced after debugging to improve delivery speed.

2.The function of transmission line is realized by the rotation of conductor itself, which makes the production of multi-angle rotation more convenient and fast.

3.The working platform can move up and down, and the forming space is larger, which provides more convenience for the production of two-dimensional products.

4.Auxiliary lifting plate: play a supporting role in the production process, avoid product deformation due to its own weight and product specificity, and ensure product stability.



Composition and description of widely used Wire Bender Bending Machine :

The machine structure consists of a machine stand and a feeding rack.

Machine platform composition:

1.feed assembly,

2.straightening frame,

3.bending assembly,

4.pneumatic system,

5.CNC electrical control part.

Functional Composition of Machine:

1.Pneumatic Unit (Controlling External Mould and Cutter Lift)

2.Feeding Assembly (Completing Material Transportation).

3.Straightening Frame (Straightening Material).

4.Bending Line Assembly (Product Forming)

  206_08


Wire Bender Bending Machine  Packaging

Stable wooden package protects machine from strike and damage.

Wound plastic film keeps machine out of damp and corrosion.

Fumigation-free package helps the smooth customs clearance.

The big size machine will be fixed in container without package.



Shipping

For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.

For FCL, we get the container and do container loading by our skillful workers carefully.



308_11

Price :  Give me reply, i will give you my favorable price immediately !

Payment term :  30% deposit and the balance paid against copy of B/L in 3 days .

Package :  Standard exporting package .

Operation manual and video disc :

When deliveryWire Bender Bending Machine , the related operation instruction of model will delivery together with machine. And in the instruction, there is teaching video disc .

After-sales service :

1.machine is simple, generally, user can understand how to operate. There is operation instruction  and disc .

2.welcome to our factory to learn how to operate our machine, we will give good training .

3.our engineer is available for user. If there is requirement, our engineer can go to user factory,  and adjust machine, give good training to user .

Automatic cnc 2D metal steel zigzag spring wire bending forming machine
