Fast dispatch high speed CNC servo wire bender 2d wire forming machine in stock

wire bender 2d without the need of the special mold, it greatly reduces the time and cost of the newly developed product; the stereoscopic molding can produce a three-dimensional shape line molding product; with an auxiliary lifting platform, it can further guarantee the production.
The stability and consistency of the product; the cutting knife can move downward to allow more space for product molding.
Diameter of wire:
Machine Type:
Material:
Applicable wire:
Control system:
Quantity:
  • ZD-2D-308
  • Greatcity
  • 8463300000

Fast dispatch high speed CNC servo wire bender 2d wire forming machine in stock


Main Features:

1. Servo drive with stable performance;



2. High precision without noise;



3. Easy to operate. Adopt special microcomputer control, intelligent forming and high efficiency;



4. Automatic straightening, wire feeding, forming, cutting and record number;



5. Wire feeding wheels, straightening wheels, forming wheels. Adopt German high quality alloy.
After vacuum heat treatment, it has high abrasion resistance and long service life;



6. Suitable for forming Various 2D shapes for all kinds of metal ( such as steel, iron,
stainless steel and aluminum wire, etc. )



7. No need molds. Just need to programme the product shape in the control computer.
One machine can bend maximum 80 products.



ZD-2D-308 model wire bender 2d technical specification:


Model

ZD-2D-308

number of  axles

3

processing wire dameter range

3—8mm (iron wire )

Number of feeder wheels (group)

3

Applicable wire

Round wire, flat wire  square wire (suitable for any wire material)

Storage

10,000 data, 300 actions in a group

minimum feeding speed(m/min)

22

Servo motor power of feeding shaft(kW)

2.6

Power of Servomotor for Cutter Shaft(kW)

2.0

Power of Folded Axis Servomotor(kW)

2.0

Direction of action

Internal and external die can be lifted and bended in both directions.

Feeding  accuracy(mm)

±0.1

minimum bending speed

800rmp/min,angle±180º

Capacity

20-24pcs/min,(200*200mm square shape)

operating system

32-bit Chinese and English (with upload and download function)

Input power supply

380V,50HZ/60HZ

weight (KG)

800

Dimension (length*width*height mm)

3000×1000×1400

wire bender 2d  video link on youtube :

https://www.youtube.com/watch?v=7aDpX4i4oNU


https://www.youtube.com/watch?v=eSYLgZhrblA

steel wire bending machine (2)

steel wire bending machine (3)

steel wire bending machine (4)

steel wire bending machine (5)

wire bender 2d Application:

 1. Auto Industry area

 2. Metal wire industry

 3. Display table and cargo shelf

 4. Furniture and Kitchen

 5. Hardware industry

 6. Mattress,Sofa spring area

 7. Architecture area

timg (23)

timg (16)

Our Advantages:

We have professional teams experting in production, design and R&D for over 10 years to meet
clients' different demands.

High precison and excellent performance for producing all kinds of springs and wire forms, Japanese
Panasonic servo motor for each machine.

wire bender 2d test run(at least for one week) before we ship the machine, in an effort to insure every
mechanical and electrical parts are in perfect condition.

 After order placed, we accept to adjust the products according to customer's demand, and remain
the program and tool settings on machine. in order to insure a quick start of machine once customer
receive it.

308_09

wire forming machine bending automatic

FAQ:

Q1: What does your factory produce ?

  A: We produce and export all kinds of automatic wire bending machine. We also can design and
develop the wire bending machines according to your requirements.



Q2: What about your standard delivery date ?

  A: Usually 20-30 days.


Q3: Does your factory sale directly ?

 A: Yes. Our factory sells directly,competitive price with high quality and excellent after-sale service.

Our quality products have been export to many countries, such as Germany, Russia, USA, Canada,
Argentina, Peru, Turkey, Iran, Brazil, Spain, South Asia and Middle East countries.



Q4: Can you export machines by your factory?

  A: Yes,we can.


Q5: Where are your factory?

  A: Our factory is located in Xingtai city, Hebei Province, China.


Q6: Will you send engineer to help installing the wire bender 2d?

  A : Yes, if you need, we can send our engineer to go to your factory to help you install our  machine,
train the workers and make sure the welding machine running well before he leaves.



Q7: If the machine get damaged, what can I do ?

   A: In the guarantee time (1 year) , we will send the spare parts to you for free and provide the
technical consultant for anytime. If more terrible, we can send our engineers to your factory.
We will provide same good after-sale service as the pre-sale service. For any of your questions,
we will reply within 12 hours.
