| Wire diameter: | |
|---|---|
| Color: | |
| Power: | |
| feeding wire:: | |
| Name:: | |
| Quantity: | |
JD-CH5
Greatcity
8463300000
Product description:
Hanger Making Machine, with a smooth operation and high production rate, while with less defective.
The line is suitable for iron wire, stainless steel wire and galvanized wire.
Servo motor adopted and frequency converter controller adopted, the machine is easy to adjust and form hangers.
Features:
1. Low maintenance cost
2. Precise positioning, high precision
3. Save labor
4. Security insurance
Hanger Making Machine video on youtube
Hanger Making Machine technical specification
Model | JD-CH5 | JD-CH-5P | JD-CH-5W | JD-CH-5W |
Wire size | 1.5-4.5mm | 1.5-4.5mm | 1.5-4.5mm | 1.5-4.5mm |
Function
| Common | PVC coating | welding | wleding and rivet end |
Welding machine | No | No | Yes | Yes |
Feeding length | 500mm(11-19inch) | 500mm(11-19inch) | 500mm(11-19inch) | 500mm(11-19inch) |
Production rate | 50~60(pcs/minute) | 30-40(pcs/minute) | 30(pcs/minute) | 30(pcs/minute) |
Motor power | 2.2kw | 2.2kw | 2.2kw | 3.7kw |
Size(mm) | 2500X1460X1580 | 2500X1460X1580 | 2700X1460X1580 | 3600X1530X16800 |
Weight | 1300KG | 1300KG | 1400KG | 1400KG |
1) Output setting, automatic control functions (production to set data automatic stop).
2) Make the body seprated, fission, when using button a machine can be used for production of other products.
3) Send line: mechanical and pneumatic in two ways.
4) The three shift transmission, three speeds are: 45 to 55 65 times/min.
5) The machine is equipped with hand rotation function, effective guarantee test without failure mould, calibration and test more convenient.
6) Hand pump oil into all lubricating points, filling of lubricating oil is convenient, avoid workers is not afraid of trouble, and lead to accelerated wear and tear parts.
Packaging information: standard export wooden case packing with strong pallet for Hanger Making Machine
We have our own farwarder. and check the delivery information timely.
You can also choose your own forwarder . We will contact with him ASAP.
Delivery time: 7-15 days after receiving the deposit
