Semi-auto clothes wire hanger making machine price

This wire hanger making machine price adopts full-automatic numerical control, accurate wire feeding, stable operation, low noise, can realize man-machine dialogue, and one machine can produce multiple hangers. A worker can manage 4-8 machines, can weld automatically, and save labor for you. The production capacity is 15 pieces per minute.

Wire diameter:
Color:
Power:
feeding wire::
Name::
Quantity:
  • JD-CH5
  • Greatcity
  • 8463300000

1.Electrical constitute

a.CNC automatic wire hanger making machine price feed mechanism 750W-2000W servo motor control, which is characterized by feeding speed, high precision length.

b. fully automatic CNC hanger molding machine of the use of three-phase 380V 1.5KW motor inverter control, easy to adjust the molding speed

c. the automatic CNC hanger molding machine operation by man-machine interface and touch panel operation buttons for automatic operation and manual operation.

2..Main advantage

a.Length Prefeeding standards

b. The speed can be adjusted according to diameter, any of the speed.

c. The high speed is fast, the fastest production can produce 45 per minute.

d. Most convenient replacement mold (hangers styles) convenient and simple, and the screen enter the required wire length, moving knife position on the line

e. The aircraft can be adapted to the production of: 201 stainless steel, 410 stainless iron, plating line, ordinary wire coated wire and aluminum wire.

wire hanger making machine price video on youtube

wire hanger making machine price technical specification

Model

JD-CH5

JD-CH-5P

JD-CH-5W

JD-CH-5W

Wire size

1.5-4.5mm

1.5-4.5mm

1.5-4.5mm

1.5-4.5mm

Function



Common

PVC coating

welding

wleding and rivet end

Welding machine

No

No

Yes

Yes

Feeding length

500mm(11-19inch)

500mm(11-19inch)

500mm(11-19inch)

500mm(11-19inch)

Production rate

50~60(pcs/minute)

30-40(pcs/minute)

30(pcs/minute)

30(pcs/minute)

Motor power

2.2kw

2.2kw

2.2kw

3.7kw

Size(mm)

2500X1460X1580

2500X1460X1580

2700X1460X1580

3600X1530X16800

Weight

1300KG

1300KG

1400KG

1400KG

hanger making machine

hanger making machine

hanger making machine

hanger making machine

hanger making machine

1. Help you choose the most suitable wire hanger making machine price

2. Making the machine according to your request.

3. Give you machine’s details  for help you use the machine more better.

4. 2 years warranty

5. Free repair whole using life without extra charge.

hanger making machine

Packaging information: standard export wooden case packing with strong pallet for wire hanger making machine price

We have our own farwarder. and check the delivery information timely.

You can also choose your own forwarder . We will contact with him ASAP.

Delivery time: 7-15 days after receiving the deposit
