good factory price for automatic small diameter wire bending machine

1. small diameter wire bending machine Replacing manual work with machine to improve production efficiency, no need to open the mould, PLC operation setting parameters for one-time forming, high forming accuracy and cost savings.
2. Suitable for iron wire, steel wire, stainless steel and non-ferrous metal wire (round, square, flat), square, round, polygon and irregular shape, all kinds of plane buckles, all kinds of hooks.

After-sales Service :
Raw Material:
Product:
Extra Services:
Control system::
Quantity:
  • JD-3D-80
  • Greatcity
  • 8463300000

small diameter wire bending machine Structural principle

1. The precision servo motor drives the wire reel to rotate. The professional line forming machine computer system is used to control each drive to perform various steps. The servo motor slow-rise ramp-down curve and servo motor speed can be arbitrarily modified according to the need to eliminate the impact of mechanical transmission. , to ensure that the actual length of the transmission line is consistent with the theoretical calculation length;
2. In the design budget, the length of each MM has been divided into 10 segments of pulses, further ensuring the accuracy of the setting of the line can be controlled at 300 ± 10 wire;
3, adjustable servo shear cutting, can ensure the neatness of the circle cut, the cutting time and the retracting time can be directly modified on the text display;
4, the design has manual slow feeding, slow returning function, easy to operate, reduce material loss


small diameter wire bending machine consists of: distribution line frame, straightening mechanism, wire feeding box, forming assembly, cutting device.
1. Wire feeder: The load of the wire and the machine keep the output of the synchronous wire;
2, straightening mechanism: straightening of the wire, the basis of molding
3. Wire feeder box: Provide servo drive force to push the wire to the forming area;
4. Molding assembly: through the folding angle of the bending head, with the work of the feeding line and the rotating arm, the wire is bent into a plane or a three-dimensional shape;
5 Cutting device: After the product is formed, it will be cut off and automatically slipped to produce the next product. This is the machine structure of the automatic wire forming machine.


small diameter wire bending machine  technical specification

Model No
JD-3D-51000
JD-3D-51200
No. of Axis
5 axis
5 axis
input OD of Wire
hard material: 3-7mm    soft material:4-8mm
hard material: 4-8mm     soft material:5-12mm
No. of Feeding Round
4 set
4set
Power of Wire Feeding Motor
5.5kw
5.5kw
Send shaft reducer
1:5
1:10
Power of Turning Motor
5.5kw
5.5kw
Power of Wire Cuter Motor
1.0kw
1.0kw
Power of Moving Motor
1.0kw
1.0kw
Power of Angle Control Motor
2.0kw
2.0kw
Angular speed reducer
1:5
1:10
Weight of Machine
3800kg
3800kg
machine wight
380V/50HZ/3PH
380V/50HZ/3PH
mahcine size
3600mm X 1600mm X 2070mm
3600mm X 1600mm X 2070mm


3d  wire bending machine video on youtube :

small diameter wire bending machine  Features
1. The fluctuation of the power supply current and voltage for more than 1 second should be within ±5%, and the equipment can operate normally.
2. The distance between the automatic feeding frame and the host is more than 2000mm.
3. The device is equipped with a USB interface for data reading.
4, the computer operating system can access the Internet to achieve remote control and operation. Production efficiency and output There is a display on the man-machine interface, and the equipment can be automatically shut down after the specified output is reached.
5. After the equipment is used, the gear box and the guide rail slider should be regularly greased for 60 working days.

wire bending machine (4)


wire bending machine (6)

wire bending machine (7)

3D wire bending machine _06 (7)

Our service

1.Any inquiries will be replied within 24 hours.
2.Professional manufacture, welcome to visit our website
3.OEM/ODM available
4.High quality, fashion designs, reasonable and competitive price, fast lead time
5.After-sale service:
All Hydraulic small diameter wire bending machine  production will have been strictly quality checked in house before packing
All products will be well packaged before shipping
All our products have 1 year warranty, and we sure the product will be free from maintenance with warranty period
6.Faster delivery: Sample order in stock, and 7-10 days for bulk production
7.Payment: You can pay for the order by T/T or L/C or Western Union
8.Shipping: We have strong cooperation with DHL,TNT, UPS, FEDEX, EMS, China Air Port, you also can choose you own shipping forwarder

3d_09

Packing of  small diameter wire bending machine
1. 1 pc wood cartton ,carton weight 1000kg,dimension:2800mm*850mm*1500mm.
2. The packing can do as customers' requirement.
Shipping
By sea to your nearest port;
By air to your nearest airport;
By express (DHL,UPS,FEDEX,TNT,EMS)to your door;
Ship to the warehouse in China according to the customers' requirement

弯线机_07

弯线机_06

Our Comopany:

We are a professional manufacturer of construction machines. We have been manufacturing small diameter wire bending machine  for some Top construction Groups from Spain, Korea and Germany since the year of 2007. Our company has got independent import and export rights. Thus, we can distribute several kinds of machine to clients globally. Some of our products have got European CE, FDA, ISO9001:2001, ISO13485:2003 and other certifications.
