ZD-2D-308
Greatcity
8463300000
Advantages of steel wire bending machine:
With straightening, with cutting, with push bending, without interference, one-time forming, unmanned operation, the efficiency is 4-5 times of the traditional model
Five
Application scope of 2D wire rod bending machine:
I. production of car seat frame, bicycle parts, basket, etc;
2. Kitchen display rack and storage rack;
3. Iron wire craft products, breeding cages, etc;
4. All kinds of display hooks;
ZD-2D-308 model steel wire bending machine technical specification:
Model | ZD-2D-308 |
number of axles | 3 |
processing wire dameter range | 3—8mm (iron wire ) |
Number of feeder wheels (group) | 3 |
Applicable wire | Round wire, flat wire square wire (suitable for any wire material) |
Storage | 10,000 data, 300 actions in a group |
minimum feeding speed(m/min) | 22 |
Servo motor power of feeding shaft(kW) | 2.6 |
Power of Servomotor for Cutter Shaft(kW) | 2.0 |
Power of Folded Axis Servomotor(kW) | 2.0 |
Direction of action | Internal and external die can be lifted and bended in both directions. |
Feeding accuracy(mm) | ±0.1 |
minimum bending speed | 800rmp/min,angle±180º |
Capacity | 20-24pcs/min,(200*200mm square shape) |
operating system | 32-bit Chinese and English (with upload and download function) |
Input power supply | 380V,50HZ/60HZ |
weight (KG) | 800 |
Dimension (length*width*height mm) | 3000×1000×1400 |
steel wire bending machine video link on youtube :
https://www.youtube.com/embed/eeFWDMDSQjc?si=97KvVO0vICSzl9aa
1. A CNC automatic wire forming machine. The angled parts cooperate with each other to produce different products. The commissioning time is short. For new products, only simple adjustments are needed. After commissioning, the products can be produced and the delivery speed can be improved.
2. The function of the transfer line is made by the rotation of the wire itself, which makes the production of multi-angled corners more convenient, faster and faster.
Price : Give me reply, i will give you my favorable price immediately !
Payment term : 30% deposit and the balance paid against copy of B/L in 3 days .
Package : Standard exporting package .
Operation manual and video disc :
When delivery machine, the related operation instruction of model will delivery together with machine. And in the instruction, there is teaching video disc .
steel wire bending machine
Packing : standardn export seaworthy wooden case
Shipment: about 3-7 days after receipt of the deposit.
By sea to your nearest port;
By air to your nearest airport;
Ship to the warehouse in China according to the customers’ requirement
after-sale service:
1. Xingtai judu technology Co., Ltd. is a powerful manufacturer. We have absolute confidence in the quality of our products and provide customers with high-quality after-sales service. All customers who buy steel wire bending machine manufacturers from greatcity enjoy within one year and lifelong system upgrade;
2. After sales service . starts 24 hours and serves you at any time;
3. In order to ensure product quality and service, all products of Xingtai judu technology Co., Ltd. will regularly call or visit customers as part of the after-sales service of greatcity machinery. Please actively cooperate with the company's personnel to call back. We will provide timely solutions and help according to the opinions and problems raised by customers;
4. The company establishes customer training system.
