ZD-2D-308
Greatcity
8463300000
General Description:
2D CNC Fully Automatic Wire Bending Machine is mainly used for bending and forming various metal wire into different shape in two-dimensional. high quality automatic 2d iron wire stirrup bending machine
The wire feeding and rotary bending system both adopt servo motor,significantly improves the precision of the product, and increases the speed and flexibility of machine effectively,furthermore greatly improves the production efficiency.
According to the characteristics of wire processing, various kinds and shapes,we specially design the controlling system with a memory storage function,which can save more than 100sets of processing program for different products, can optionally select any one of them when needed. easy operating and cheap price Automatic CNC 2D Wire Bending Machine
ZD-2D-308 model cnc head 2d wire bending machine technical specification:
Model | ZD-2D-308 |
number of axles | 3 |
processing wire dameter range | 3—8mm (iron wire ) |
Number of feeder wheels (group) | 3 |
Applicable wire | Round wire, flat wire square wire (suitable for any wire material) |
Storage | 10,000 data, 300 actions in a group |
minimum feeding speed(m/min) | 22 |
Servo motor power of feeding shaft(kW) | 2.6 |
Power of Servomotor for Cutter Shaft(kW) | 2.0 |
Power of Folded Axis Servomotor(kW) | 2.0 |
Direction of action | Internal and external die can be lifted and bended in both directions. |
Feeding accuracy(mm) | ±0.1 |
minimum bending speed | 800rmp/min,angle±180º |
Capacity | 20-24pcs/min,(200*200mm square shape) |
operating system | 32-bit Chinese and English (with upload and download function) |
Input power supply | 380V,50HZ/60HZ |
weight (KG) | 800 |
Dimension (length*width*height mm) | 3000×1000×1400 |
Greatcity brand cnc head 2d wire bending machine and 2d Wire Bender Machine 2D Automatic cnc wire bending machine 3D/2D CNC steel wire bending machine manufacturer easy operating and cheap price Automatic cnc 2D metal steel zigzag spring wire bending forming machine
Both the inner and outer molds can be rotated and lifted. The Taiwan motor and numerical control system have the characteristics of fast wire feeding, high precision, large memory, high flatness, easy operation and easy operation.
cnc head 2d wire bending machine Packaging
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.
Shipping
For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.
For FCL, we get the container and do container loading by our skillful workers carefully.
1. Q: Are you a factory or trading company?
A: We have our own factory and have been over 10 years. Have rich experience in export
We have the improvement teams from design, manufacture....to installation, commissioning and staff training
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Xingtai City, the capital of Hebei Province, 1.5 hours way by high-speed rail from Beijing to Xingtai
3. Q: How does your factory do regarding quality control?
A: We test our machine before shipping. We have CE certificate.
4. Q: What shape and size can the machine make?
A: It adopt aptitude control . Can processing many size and specification shape . For example :square , rectangle , rhombus ,polygon and so on .
5. Q:What is the Mode of transportation ?
A:LCL and FCL by ship ,By Express (DHL,TNT, Fedex etc) ,By air
6. Q:How should I do if meet some trouble while using?
A:we can supply English manual book and also take a video for showing how to resolve the problems or dispatch our worker to your factory.
