Z28-200
Greatcity
8462419000
metal screw bolt making thread rolling machine is divided into two axis rolling machine and three axis thread rolling machine
1, two axis wire rolling machine has very strong superiority in hardware building, automobile and motorcycle fittings, traffic power, standard parts.
2, three axis rolling machine is triangle support in the pipe thread processing industry, true fidelity roundness, concentricity and perpendicularity
It is a multifunctional cold extrusion rolling thread machine, the workpiece in the cold rolling pressure range can be made to straight lines, twill, spur, helical and bevel gear spline rolling; straightening, necking, rolling light and various rolling forming. The machine has safe and reliable electric liquid control system and implementation, which can make each work cycle in manual, semi-automatic and automatic selection in three ways. The cold rolling is an advanced non cutting process, which can effectively improve the internal and surface quality of workpiece, the radial compressive stress produced during processing, and can significantly improve the fatigue strength and torsion strength of the workpiece. It is an ideal process with high efficiency, energy saving and low consumption.
The metal screw bolt making thread rolling machine can equipped the auto feeding and loading machine. pls inquiry for details.
SPECIFICATIONS FOR GREATCITY bolt thread rolling machine ZP28-200 | |||
Rolled thread range | mm | Φ5-65 | |
Hobbing wheel range | mm | outside dia:Φ120-170 hole dia:Φ75 Max width:100 | |
Maximum rolling pressure | kn | 200 | |
Main axis | . | Obiquity +5 | |
Hydraulic auto feeding time regulation range | s | 0.1-99.9 | |
Cease time regulation range | s | 0.1-99.9 | |
sMain axis transmission power | kw | 11kw-4 | |
Hydraulic transmission power | kw | 2.2 | |
machine weight | kg | 2800kg | |
Dimensions | mm | 2500*1450*1650 |
bolt thread rolling machine video link on youtube :
https://www.youtube.com/watch?v=D_t1gnynkCs
1, Q: How about the after service?
A: We have a strong team, special for after service. We can arrange engineers to do service for you.
2, Q: Are you factory or trading company?
A: We are a factory in this field nearly 15 years
3, Q: Where is your factory located? How can I visit there?
A:Our factory is located in Xingtai City. Hebei province. You can fly to zhengding airport and or by high-speed train directly. I will pick you up .
4, Q:How does your factory do regarding bolt thread rolling machine quality control?
A:Quality is priority. We always attach great importance to quality controlling from the beginning.
5, Q: why choose GREATCITY Machinery?
A: We are one of leader in this field(in China). Our quality products and service have enabled us to expand our market from china to more than 60 countries.
