Pneumatic copper flat wire bending machine

flat wire bending machine is to produce kinds of 5-12mm diameter 2D wire forms expertly with high precision and fast speed. Adopts brand servo motor and screen display with top controller.
Advantages & Feature:
1. The error of full servo motor is smaller, the bending efficiency is higher, and the error is smaller than that of similar products of hydraulic press.
2. CNC operation is simpler and easier to learn than the same type of PLC products. Generally, the simple program can be edited by oneself within half an hour with elementary school education.
3. Because all the servo motors are used, there will be no hydraulic failure, the failure rate is lower, the scrubbing is more convenient, and the pollution caused by oil pollution will not occur.
Diameter of wire:
Machine Type:
Material:
Applicable wire:
Control system:
Availability:
Quantity:
  • ZD-2D-612

  • Greatcity

  • 8463300000

flat wire bending machine is to produce kinds of 2D wire forms expertly with high precision and fast speed. Adopts brand servo motor and screen display with top controller.



Advantages & Feature:

1. The error of full servo motor is smaller, the bending efficiency is higher, and the error is smaller than that of similar products of hydraulic press.

2. CNC operation is simpler and easier to learn than the same type of PLC products. Generally, the simple program can be edited by oneself within half an hour with elementary school education.

3. Because all the servo motors are used, there will be no hydraulic failure, the failure rate is lower, the scrubbing is more convenient, and the pollution caused by oil pollution will not occur.



flat wire bending machine Application field :

1)Auto Industry area
2)Metal wire industry

3)Display table and cargo shelf
4)Furniture and Kitchen

5)Hardware industry
6)Mattress, Sofa spring area
7)Architecture area
8)Hardware Artcraft


ZD-2D-612 model flat wire bending machine technical specification:


Model

ZD-2D-612

number of  axles

3

processing wire dameter range

6—12mm (iron wire )

Number of feeder wheels (group)

3

Applicable wire

Round wire, flat wire  square wire (suitable for any wire material)

Storage

10,000 data, 300 actions in a group

minimum feeding speed(m/min)

22

Servo motor power of feeding shaft(kW)

4.5

Power of Servomotor for Cutter Shaft(kW)

2.3

Power of Folded Axis Servomotor(kW)

3.8

Direction of action

Internal and external die can be lifted and bended in both directions.

Feeding  accuracy(mm)

±0.1

minimum bending speed

800rmp/min,angle±180º

Capacity

20-24pcs/min,(200*200mm square shape)

operating system

32-bit Chinese and English (with upload and download function)

Input power supply

380V,50HZ/60HZ

weight (KG)

2300

Dimension (length*width*height mm)

3250×1200×1300

flat wire bending machine video link on youtube

https://www.youtube.com/embed/eeFWDMDSQjc?si=97KvVO0vICSzl9aa

flat wire bending machine (6)flat wire bending machine (7)

flat wire bending machine (4)

flat wire bending machine (1)flat wire bending machine (2)flat wire bending machineworkpiece


wire bending machine 3pgwire bending machine 4 jpgsend inquiry 1

The process shapes of automatic flat wire bending machine

Our machine could process 500 kinds shapes

Main accessories of wire bending machine

wire bending machine

wire bending machine

IMG_20190805_144359

flat wire bending machine

Founded in 1998, Xingtai Judu Technology Co.,ltd specialized in manufacturing all kinds of machinery. Our products now include 3D wire bending machine,2D wire bending machine, bucket handle machine, paint roller machine, thread rolling machine,CNC stirrup bending machine and so on. At the same time, we can produce according to our customers request. These products have been exported to the USA, Germany, Pakistan and Australia. We have 20 machine designer, 50 engineers and 300 workers. Our factory located in Xingtai, Hebei province, in a district known as machinery hometown, occupying an area of 30,000 square meters. We have more than 100 sets of equipments, which are operated by 300 workers. We also have a highly qualified technical team engaged in developing new items and dealing clients customized orders. Our annual export amount is over USD9,000,000. Having developed more than 500 kinds of machinery in the past 20 years, we are marketing all series under our brand. Working in line with the principle of " integrity, quality, service" we have already obtained ISO certification, meanwhile, all products meet the requirements of CE standards, with good quality, our products enjoy a high reputation among all clients, having cooperate with many famous machinery importers. Our company promise: Reasonable prices, short production time and satisfactory after-sales service. We are confident in producing the best machinery and service, please feel free to contact with us if you are interested in any of our machinery. We are honored to have opportunity of establishing a business relationship with your esteemed company.
Why Choose Us

flat wire bending machineflat wire bending machineachine, paint roller machine, thread rolling machine,CNC stirrup bending machine, nail making machine, screw making machine and so on. At the same time, we can produce according to our customers request. These products have been exported to the USA, Germany, Pakistan and Australia. We have 20 machine designer, 50 engineers and 300 workers. Our factory located in Xingtai, Hebei province, in a district known as machinery hometown, occupying an area of 30,000 square meters. We have more than 100 sets of equipments, which are operated by 300 workers. We also have a highly qualified technical team engaged in developing new items and dealing clients customized orders. Our annual export amount is over USD9,000,000. Having developed more than 500 kinds of machinery in the past 20 years, we are marketing all series under our brand. Working in line with the principle of " integrity, quality, service" we have already obtained ISO certification, meanwhile, all products meet the requirements of CE standards, with good quality, our products enjoy a high reputation among all clients, having cooperate with many famous machinery importers. Our company promise: Reasonable prices, short production time and satisfactory after-sales service. We are confident in producing the best machinery and service, please feel free to contact with us if you are interested in any of our machinery. We are honored to have opportunity of establishing a business relationship with your esteemed company. Why Choose Uspacking and shipping

 Flat Wire Bending Machine

Packaging

Stable wooden package protects machine from strike and damage.

Wound plastic film keeps machine out of damp and corrosion.

Fumigation-free package helps the smooth customs clearance.

The big size machine will be fixed in container without package.



Shipping

For LCL, we cooperated with reputable logistics team to send machine to sea port speedily and safely.

For FCL, we get the container and do container loading by our skillful workers carefully.

FAQ


FAQ:


1.what is  Flat Wire Bending Machine  Packaging?
Free fumigation safe Wood case package.
2.what is MOQ?
1set can be acceptable for trail order.
Over 1 sets can have wholesale price. Welcome to join us as our sales agent in your market.
3.can we do OEM and ODM?

Can changing on design , color ,: acceptable(welcome)
develop on artwork and sketch : acceptable
4.what is your warranty?

Warranty 1 year
5.what time for delivery?
7-10 days for our own design.(motor:380v 50hz 3phases)
15-20 days for cusmoized model.
6.How to do payment?
TT, 40-50% in advance as deposit ,balanced paid off when we finish the production and test well before shippment.
