Manufacturer Famous Brand Greatcity 3d Wire Bending Machine for Sale South Africa

1 wire bending machine for sale south africa Replacing manual work with machine to improve production efficiency, no need to open the mould, PLC operation setting parameters for one-time forming, high forming accuracy and cost savings.
2. Suitable for iron wire, steel wire, stainless steel and non-ferrous metal wire (round, square, flat), square, round, polygon and irregular shape, all kinds of plane buckles, all kinds of hooks.

After-sales Service :
Raw Material:
Product:
Extra Services:
Control system::
Quantity:
  • JD-3D-80
  • Greatcity
  • 8463300000

Prouct introduction:

It is a wire bending machine for sale south africa controlled by industrial computer, the design of which mainly aims at forming & processing of medium batch and large batch of round wire and square stock and settling the instable conditions of manual processing. Additionally, it can greatly reduce switching time and quantity of waste products, and can switch products at real time under the conditions of same wire diameter and existing program.
The bending method is to adopt the computer to switch the twist-aided rotary core with different external diameter and control the rotation angle of twist head and then cooperate with the wire/stock feeding in order to meet the requirement of bending different angle and diameter; therefore, it needs no specialized or complicated mold for forming which greatly reduces the time and cost required by developing new product.
This model is mainly for the kitchen&bath accessories, supermarket appliance, automotive sun visor skeleton, car door lock rod, designed for a variety of wire forming, with full processing capacity and high processing speed and accuracy.


wire bending machine for sale south africa technical specification

Note that any customization is permissible

Model

3D

Diameter

Steel: 2-6 mm

Ordinary wire: 2-10 mm

Type

hydraulic

Hydraulic power motor

2.2 kW

Motor power servo motor

5.5 kW

Feeding wire

10000.00 mm

Traction Servo speed

1:20

Molding/ turning speed

1:5

Molding /turning power

3.8*2 kW

Lifting/ turning servo

1:5/1:20

Lifting / turning servo

0.75*2 kW

Control shaft system

5

Molding machine size

3*1.35*1.95 mm

Motorized machine size

1*1*0.75 mm

Input voltage

380V/50Jz/3Ph

Net weight

2.8 T


wire bending machine for sale south africa video on youtube :

wire bending machine for sale south africa Main Features

1) Simple structure in linear type ,easy in installation and maintation.

2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure double crank to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .


3d wire bending machine


3d wire bending machine


3d wire bending machine



wire forming machine

3d_05


3d_07

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.


3d_09

wire bending machine for sale south africa

Packing: In standard export wooden case

Delivery time:within 15 days after receiveing your advanced payment.

Payment terms:. 30%T/T in advanced payment,the left payment should be paid after we finish our production.( we will take  machine and packing photoes for your checking )

We have our own farwarder. We can check the delivery information timely. You can also use forwarder by yours. We will contact with him ASAP.


3d_07

FAQ

1 Q: Where is your factory located? How can I visit there?

A:Our factory is located in Xingtai City. Hebei province. You can fly to zhengding airport and or by high-speed train directly. I will pick you up .



2.Q:How does your factory do regarding wire bending machine for sale south africa quality control?

A:Quality is priority. We always attach great importance to quality controlling from the beginning.and we have CE  certificate.



3. Q: How does your factory control the quality?
A: We have the professional QC group inspect the details in each process.After finishing the goods, our QC will inspect piece by piece.



3d_08
