Z28-200
Greatcity
8462419000
Mainly used for all kinds of external thread, including the common thread, trapezoidal thread and modulus thread. It also can do the rolling process, forming, slidabrading, knurling etc..
Apply for all kinds of carbon steel, alloy steel and non-ferrous metals, the elongation is more than 10%, the compressive strength is less than 100 KGF/m m2.
Description of screw thread rolling machine
Z28-200 type rebar thread rolling machine main purpose
Rolling Hercules, five-speed gearbox, a wider range of applications
The model rebar thread rolling machine is Large processing capacity,the transmission part of the gear module and output power are greater than the general gear box,thus solving the same type can not be processed trapezoidal thread.Modular thread and the problem of the opposite sex thread,free from chaos buckle
SPECIFICATIONS FOR GREATCITY screw thread rolling machine ZP28-200 | |||
Rolled thread range | mm | Φ5-65 | |
Hobbing wheel range | mm | outside dia:Φ120-170 hole dia:Φ75 Max width:100 | |
Maximum rolling pressure | kn | 200 | |
Main axis | . | Obiquity +5 | |
Hydraulic auto feeding time regulation range | s | 0.1-99.9 | |
Cease time regulation range | s | 0.1-99.9 | |
sMain axis transmission power | kw | 11kw-4 | |
Hydraulic transmission power | kw | 2.2 | |
machine weight | kg | 2800kg | |
Dimensions | mm | 2500*1450*1650 |
screw thread rolling machine video link on youtube :
https://www.youtube.com/watch?v=PJHxY6FLL4Y
Xingtai Judu Technology Co.,LTD was founded in 1990,Specialized in machinery production & export of screw thread rolling machine,has been in this field for more than 20 years.The Hydro construction machines,such as z28-150b, z28-200 z28-65 are our advantages machine. These machines now export to all over the world such as Asia,Africa,South America,Australia and so on
Packaging & Shipping:
Packaging information: standard export non-fumigation wooden packing for screw thread rolling machine.you can choose by sea container or train We have our own farwarder. We can check the delivery information timely. You can also use forwarder by yours. We will contact with him in the first time.
Shipping time:within 10-15 days after receiving the deposit.
1, Q: How about the after service?
A: We have a strong team, special for after service. We can arrange engineers to do service for you.
2, Q: Are you factory or trading company?
A: We are a factory in this field nearly 15 years
3, Q: Where is your factory located? How can I visit there?
A:Our factory is located in Xingtai City. Hebei province. You can fly to zhengding airport and or by high-speed train directly. I will pick you up .
4, Q:How does your factory do regarding screw thread rolling machine quality control?
A:Quality is priority. We always attach great importance to quality controlling from the beginning.
5, Q: why choose GREATCITY Machinery?
A: We are one of leader in this field(in China). Our quality products and service have enabled us to expand our market from china to more than 60 countries.
